产品参数

处理器          SW1610,主频1.4GHz                             电源供电           +3.3V，+5V,+12V

芯片组          PEX8X48                                                模块功耗           不大于100W

内存类型        DDR3 SDRAM颗粒，容量16GB            工作温度           -40ºC~+65ºC

板载存储体      7+15Pin SATA连接器                          存储温度           -50ºC~+85ºC

显示接口        1路VGA接口                                         散热方式           兼容传导散热和对流散热

USB接口         4路USB2.0                                           结构类型           6U CPCIE

存储接口        2路SATA2.0                                          结构尺寸           233.35mm*160mm

网络接口        4路1Gb Ethernet                                  软件支持           国产UEFI固件\国产Liunx系统

扩展接口        4路PCI-E Ports,16路PIC-E Lanes

BMC功能         IPMI\健康管理
