产品参数

处理器          FT1500A/16,主频1.5GHz                                电源供电           +12V

芯片组         PEX8X48                                                          模块功耗           不大于90W

内存类型        DDR3 SDRAM颗粒，容量32GB                      工作温度           -40ºC~+65ºC

板载存储体       7+15Pin SATA连接器                                  存储温度           -50ºC~+85ºC

显示接口        3路DVI接口                                                    散热方式           兼容对流散热和传导散热

USB接口        4路USB2.0,2路USB3.0                                    结构类型           6U VPX

存储接口       1路SATA2.0                                                    结构尺寸           233.35mm*160mm

网络接口        4路1Gb Ethernet                                           BMC功能         IPMI\健康管理

串行接口        3路RS-422                                                     软件支持           国产UEFI固件\国产Liunx系统
