产品参数

处理器          FT1500A/16,主频1.5GHz                                          电源供电           +3.3V，+5V

芯片组         PEX8X48                                                                    模块功耗           不大于95W

内存类型        DDR3 SDRAM颗粒，容量16GB                                工作温度           -40ºC~+65ºC

板载存储体       7+15Pin SATA连接器                                             存储温度           -50ºC~+85ºC

显示接口        1路VGA接口,2路DVI接口                                           散热方式           兼容对流散热和传导散热

USB接口        4路USB2.0,2路USB3.0                                               结构类型           6U CPCI

存储接口       2路SATA2.0                                                                结构尺寸           233.35mm*160mm

网络接口        4路1Gb Ethernet                                                       BMC功能         IPMI\健康管理

串行接口        2路RS-232,2路RS-422                                                软件支持           国产UEFI固件\国产Liunx系统

其他接口        MIC/LINE_OUT
